Mudhawk 110

ENGINE Type: 107cc, Air cooled, 4-stroke, 1-cylinder
Bore×Stroke: φ52.4×49.5mm
Compression Ratio: 9.2:1
Carburetor: PZ20
Ignition: CDI
Starting: Electrical start
Transmission: F-N-R
Drive Train: Chain drive
Max. Power: 4.5Kw/8000r/min
Max. Torque: 6.9N.m/6000r/min
Suspension/Front: Independent double shock absorber
Suspension/Rear: Single shock absorber
Brakes/Front: Drum
Brakes/Rear: Ventilated Hydraulic disc
Tires/Front: 16×8-7
Tires/Rear: 16×8-7
Overall Size (L*W*H): 1340*790*900mm
Seat Height: 600mm
Max. Speed: 50km/h
Battery: 12V4Ah
Fuel Capacity: 2.2L
Dry Weight: 99kg
Max. Load: 85kg
Package Size: 1275X750X590mm
Loading Quantity: 39pcs/20´GP, 108pcs
Max. Speed: 50km/h
